Niveland^® 10R

Technical Characteristics

Product based on special cements, selected aggregates, fibers, and additives.

Advantages and Uses

• Indoor floor levelling.
• High mechanic resistance.
• High resistance to abrasion.
• Excellent levelling qualities.
• Fast setting.
• Up to 10 mm thickness.
• Suitable for radiant heating where levelling on previous screed is needed.

Suitable Substrates

• Concrete, mortar screeds and similar elements.
• Substrates must be resistant, stable, sound and clean, free of dust, demolding agents, organic products, etc.
• Apply Paviland Primer R to avoid the formation of air bubbles in the mortar and improve its adhesion to the substrate.
• If necessary, prepare the surface by mechanical means, to eliminate the laitance and get the adequate porosity.
• Before the application of NIVELAND 10R, holes and/or cracks in the support must be properly repaired using the adequate products of the Paviland or Morcemrest range.
• Before applying the mortar, make sure that residual moisture is below the limit  (less than 3%).

Application Procedure

• Mix the product with water (4.5-5.0 liters per 25 kg bag) with a mechanical mixer at low speed (500 rpm approximately) until getting a homogeneous paste without lumps. The exact water dosage is especially important to avoid product segregation, increased shrinkage, and reduced strength.
• Let the mixture stand for 2 minutes and remix.
• The pot life of the mortar is 20 minutes, depending on the
• Pour the mixed product on the base to be set and spread with a levelling trowel weather conditions..
• The recommended thickness is 2 – 10 mm. applied in one coat.

Recommendations

• Do not apply in temperatures under 5ºC nor above 30ºC.
• Do not apply when there is a risk of frost, strong wind or direct sun.
• Not recommended for exterior use.
• Do not apply on floor with humidity or with a risk of having it.
• Once the product has been mixed and the resting time has occurred, do not add additional water.   Keep in mind the workability time of the product when planning  the work.
• For floors larger than 20 m² or longer than 10 lineal meters, it is advisable to make partitioning joints, delimiting panels with 6 mm joints that can be sealed with PUMALASTIC MS or PU.
• Movement joints on the original substrate must be respected and perimitral joints made.
• The surface coat must be protected from drying too quickly, especially in conditions with high temperatures and/or strong winds.
• Before laying the final flooring check the residual humidity of the floor and confirm it is adequate for the type of flooring to be installed.
• The NIVELAND 10R must be covered, as it is not suitable for leaving exposed.

Packaging and Storage

25 kg plastic-lined paper bags.
6 months in sealed original packaging, sheltered from weather conditions and humidity.

Technical data

(Statistical data obtained under standard conditions)

NOTE: Times shown relate to 23ºC temperature and 50% relative humidity. Such times are shorter at higher temperatures and longer at lower temperatures.

CE Mark

GRUPO PUMA ESPAÑA S.L Avda. AGRUPACIÓN CÓRDOBA, Núm. 17 14014 CÓRDOBA 26
NIVELAND 10R Nº: 500551-01 EN 13813 Fast-setting, fibre-reinforced cement-based self-levelling compound, type CT C30 F5, for the preparation of interior floors and the installation of light floor coverings such as ceramic, parquet, carpet, etc., for thicknesses from 2 to 10 mm.
Reaction to fire	Class A1
Emission of corrosive substances	CT
Resistance to compression	C30
Resistance to bending	F5
Hazardous substances	See safety datasheet

Environmental Product Declaration (EPD)

Cement based mortar prepared with aggregates that are supplied close to the production center, which reduces the greenhouse gas emissions that would otherwise arise from their transport. Manufactured in production centers with an Environmental management certified system following ISO 14001 regulation, offering a firm promise of sustainability and respect for the environment.
Cement based mortar with type III ecological label (the most strict) Environmental Product Declaration verified externally by AENOR.


Notas

The instructions for use are given according to our tests and knowledge and do not imply any commitment by GRUPO PUMA nor free the consumer from the examination and verification of the products for their correct use. Claims must be accompanied by the original packaging to allow a proper traceability.

GRUPO PUMA is not responsible, in any case, for the application of its products or constructive solutions carried out by the application company or other parties involved in the process and / or execution of the work, limiting the responsibility of GRUPO PUMA exclusively to the damages directly attributable to the supplied products, individually or integrated in systems, due to failures in their manufacturing process.

In any case, the drafter of the work project, the technical management or the person responsible for the work, or collaterally the application company or other parties involved in the process and / or execution of the work, must ensure the suitability of the products addressing the characteristics of them, as well as the conditions, support and possible pathologies of the work in question.

The values obtained by GRUPO PUMAS's products or its constructive solutions that, as the case may be, are determined by the EN standards or any other regulation that applies to it in each case refers exclusively to the conditions specifically stipulated in said regulation and that are referred to, among others, to certain characteristics of the support, humidity and temperature conditions, etc. without being them required in the tests obtained under different conditions, all in accordance with the relevant regulation.
